NOMO’S HPN series:Whole brand new upgrade series solar street light with delicate design, adopt upgrade all-aluminium alloy material,achieve better heat dissipation and 100% waterproof which maintain longer lifetime. All parts are separate individually, unique buckle design, enable installing the light within minutes without tool,save more time and cost,especially convenient for SKD service. Not only can it self-activated by sunlight without switch，also built in four kinds of remote-controllable working mode for option.
Lighting |
|
| Light output | 12000LM |
| LED Chip | 5050 |
| CCT | 2700-6000K ( can be customized) |
| Life Span | 100,000 hours to LM80 specifications |
| Working Way | Motion Sensor/IOT/Time Schedule |
Solar Panel |
|
| Power of PV module | 80W |
| Life Span | 25 years |
Storage |
|
| Battery Capacity | 550WH |
| Autonomy | >10 days |
| Life Span | 4000 cycles ( 10 years) |
Charging Controller |
|
| Life Span | >12 years |
Mechanical Specifications |
|
| Recommened Pole Height | 8m-10m |
| Recommended Top diameter of the Pole | 76mm |
| Product Dimension (mm) | 1206*406*84mm |
| Weight（Kg) | 25.6kg |
Environment |
|
| Working Temperature | ‘-15°C to +70°C |
| Water Resistance | IP65 |
Whole brand new upgrade series solar street light with delicate design, adopt upgrade all-aluminium alloy material,achieve better heat dissipation and 100% waterproof which maintain longer lifetime.
All parts are separate individually, unique buckle design, enable installing the light within minutes without tool,save more time and cost,especially convenient for SKD service.
Energy pack is like a drawer which contains battery pack and MPPT, it has best waterproof to protect the lamp well. Meanwhile It's very easy to replace.
Comparing with the regular solar light which only can work with low power or shorter time, we adopt the newest generation LiFePO4 battery, it has a longer lifespan, up to more than 4000 circles, and enable to work 12 hours continuously at least with 100% power output. Even at ambient temperature 75 degrees, the battery in the lamp still can discharge normally due to its high temperature-resistance.
The fourth generation controller is more efficient and stable than the third generation controller. At the same time, it has the Internet of Things function and automatic cleaning function of solar panels.
High efficiency long life LED module with SMD LED package mounted on MCPCB.Lumen efficacy of LED ≥220 lm/W.
Batwing optical design with PMMA material, vastly improve the illumination area and has highly-uniform illumination. and transmittance rate is up to 94%
