| Model No | 51.2V-100Ah |
| Nominal Voltage(V) | 51.2V |
| Nominal Capacity(Ah) | 100 |
| Max.Energy(kwh) | 5.12 |
| Vcharge-Dischage Current(A） | 100 |
| Voltage Window(V) | 43.2-58.4 |
| Charge Voltage(V) | 56.8-58.4 |
| Dimensions(Height*Width*Depth mm) | 640*395*200 |
| Net Weight(Kg) | 58 |
| Designed Life | 10+years |
| Cycle Life | More than 6000 [email protected]℃ 0.5C 80%DOD |
| Discharge Temperature | ’-20+60℃ |
| Temperature & Period Storage | 12 [email protected]~35℃ |
| 3 [email protected]~45℃ | |
| 7 [email protected]~60℃ | |
| Communication | CAN/RS485/RS232/Dry Contact/ Bluetooth（Optional) |
| Certification Standard | IEC62619/TUV/UN38.3/ROHS/CE |
